Description
What this wiring diagram covers
This BMW F800R wiring diagram is the BMW electrical diagram for the 2005-2019 BMW F800R (K73), supplied as an English PDF.
Each circuit shows the component code, plug and pin number, signal name, wire cross-section in mm² and wire colour. Supply lines are colour-coded: red for the permanent battery feed (terminal 30), green for the switched ignition feed (terminal 15) and brown for ground. Twisted and shielded lines are marked.
The connector section shows the face of each plug with its pin numbers.
Systems shown
- Positive and ground distribution, control unit supply
- Digital engine electronics (DME): power supply, control unit and component groups
- Air supply, idle speed control
- Fuel supply, fuel injectors, ignition coils
- Crankshaft sensor, temperature sensors, coolant temperature and fan
- Oxygen sensor, exhaust-flow control valve servomotor, secondary air system
- Starter motor, alternator
- Oil pressure switch, transmission position sensor
- Lighting, turn indicators, horn
- ABS and instrument panel
- Alarm system (DWA) and tyre pressure control (RDC)
- Charging socket, heated grips, diagnostic connector, optional accessories plug (SZ)
What else is in the PDF
- Legend of components, plugs and cable connectors with BMW codes and names (e.g. A9500 engine control unit, X9590 diagnostic connector)
- Wire colour key: BL blue, BR brown, GE yellow, GN green, GR grey, OR orange, RT red, SW black, TR transparent, VI violet, WS white, RS pink
- Symbol key: pin and bushing contacts, ground points, twisted and shielded lines
- Searchable text and bookmarks for each system and connector
Models covered
- BMW F800R (K73)
Years covered
- 2005
- 2006
- 2007
- 2008
- 2009
- 2010
- 2011
- 2012
- 2013
- 2014
- 2015
- 2016
- 2017
- 2018
- 2019
FAQ
Does it fit my 2014 BMW F800R?
Yes. It covers the 2005-2019 BMW F800R (K73). Please leave your BMW model code in the order notes when you buy.
How do I find my model code?
It is the 4th to 7th characters of your VIN. For example, in WBx0K63xxxxxxxxxx the model code is 0K63.
Does it show wire colours and pin numbers?
Yes. Every wire has its colour code and size in mm², and every plug shows its pin numbers.
Can I see a sample before I buy?
Yes. Ask us for a sample wiring diagram.
How do I get the wiring diagram after payment?
You receive a download link (OneDrive) by email after payment. You get a download link only.
More manuals: BMW F800R manuals.
