Description
This Honda NX500 service manual covers the 2024-2025 Honda NX500, CB500X, CB500F and CBR500R with the 471cc parallel-twin engine.
The file is a 555-page scanned PDF in English (Honda part code 61MLR00). It has the workshop service information, maintenance specs, repair procedures, electrical system and wiring diagrams for these models.
Use it for servicing, fault-finding and repairs at home or in a workshop. It is a scanned PDF, not an editable document. You can save it to your device and print the pages you need.
Models covered
- Honda NX500
- Honda CB500XA (CB500X)
- Honda CB500FA (CB500F)
- Honda CBR500RA (CBR500R)
Years covered
- 2024
- 2025
What is inside
- Periodic maintenance
- Fuel system
- Engine top end
- Clutch
- Engine lubrication system
- Engine removal and installation
- Crankshaft
- Transmission
- Wheels and tyres
- Final drive
- Brakes
- Suspension
- Steering
- Frame
- Electrical system
- Self-diagnosis system
- Wiring diagram
Useful details
- Engine: 471cc, 2-cylinder parallel twin
- Transmission: constant mesh, 6-speed
- Valve clearance, intake: 0.16 ± 0.03 mm (0.006 ± 0.001 in)
- Valve clearance, exhaust: 0.27 ± 0.03 mm (0.011 ± 0.001 in)
- File: scanned PDF, 555 pages, English
- Honda part code: 61MLR00
- Wiring diagrams: included
- Delivery: download link by email after payment
FAQ
What oil does the Honda NX500 take, and how much?
SAE 10W-30 motorcycle oil to JASO MA, API SJ or higher. The NX500 takes about 2.6 litres with a filter change and 2.4 litres without. The CB500F and CBR500R take about 2.7 litres with a filter change.
How often should I change the oil and filter?
First oil change at 1,000 km (600 miles). After that, change the oil every 12,800 km (8,000 miles) or every year, and the filter every 25,600 km (16,000 miles). Don’t overfill.
When do the valve clearances need checking?
Every 25,600 km (16,000 miles). The valves are shim-type. Cold clearances are 0.16 ± 0.03 mm intake and 0.27 ± 0.03 mm exhaust.
What chain and sprockets does the NX500 use?
A 15-tooth front sprocket, a 41-tooth rear sprocket and a 520 O-ring chain with 112 links. Chain slack is 30-40 mm on the NX500 and 25-35 mm on the CB500F and CBR500R.
What is the difference between the NX500 and the CB500X?
The NX500 replaced the CB500X and keeps the same 471cc twin with an updated ECU. It adds Honda Selectable Torque Control, a 5-inch TFT screen, lighter wheels, new LED lights and revised suspension, and is about 3 kg lighter.
Are wiring diagrams included?
Yes. The wiring diagrams are in the PDF, along with the electrical system and self-diagnosis sections.
How do I get the manual after payment?
You receive a download link by email after payment. You can save the PDF and print the pages you need.
